Aeromotive Universal Brushless In-Tank Pump, 3.5gpm Spur Gear

Part Number 18374 Universal3.5 Brushless Stealth Gear Pump
Pro-Series Performance Plus Advanced Technology

This configuration features a universal filter pickup, for an overall height adjustment from 10-16in.

• The Pro-Series performance you expect and more:

  • Fuel injected engines:
    up to 2400 FWHP naturally aspirated
    up to 1800 FWHP forced air induction
  • Carbureted engines:
    Up to 2600 FWHP naturally aspirated
    Up to 2000 FWHP forced air induction

• E85 Compatible, reduce max FWHP by 30%
• Lighter than the traditional Pro-Series pump.
• Reduced current draw at higher, EFI pressures.
• Extended service life in methanol and ethanol.
• New integral spur-gear pumping mechanism.
• 90-PSI continuous operating pressure and up to 150-PSI peak pressure, base plus boost.
• Integral, external brushless controller for clean installation, cooler fuel and enhanced reliability.
• ORB-10 outlet port.
• Requires straight 12-VDC to 16-VDC power supply.
• Not compatible with pulse modulated systems or fuel pump speed controllers.

EFI Rated flow of 1,250 lbs./hr. @ 40 psi, 13.5 volts
Carb Rated Flow of 1,350 lbs./hr. @ 9 psi, 13.5 volts
