Sale! Megan Racing 20pc Extended Wheel Studs – Mitsubishi EVO 8/9 (2003-2007)
$42.50
$85.00
Quick Overview
Megan Racing extended wheel studs are made with heat treated high strength chromoly steel. Lost of threading on stock studs can be a major safety issue, these extended studs are essential upgrade for added spacers or aftermarket thick-center wheels. These
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
Megan Racing extended wheel studs are made with heat treated high strength chromoly steel. Lost of threading on stock studs can be a major safety issue, these extended studs are essential upgrade for added spacers or aftermarket thick-center wheels. These studs are intended to be used with open-ended lug nuts.
Applications:
– Mitsubishi EVO8 or EVO9 2003-2007
– Package of 20 Extended Wheel Studs
Thread Size: 12mm x 1.5RH
Knurl Size: 14.50mm
Thread Length: 52mm
Overall dimension of stud (see diagram)
D1: 18.75mm
D2: 12.10mm
D3: 12mm
L1: 5.50mm
L2: 8.50mm
L3: 5.50mm
L4: 62mm
*Note: Recommended to be used with wheel spacers up to 20mm, 5-6 full turns of lug nut to secure with use of torque wrench.
